SEGMENTS GM350 2 X 1.5 X 4 - 0.30
Set of rings for a piston in dimension 0.30 with dimensions 2 x 1.5 x 4mm.
DAM Marine possède plusieurs produits en stocks qui pourraient vous être utiles.
Set of rings for a piston in dimension 0.30 with dimensions 2 x 1.5 x 4mm.
Set of rings for a piston measuring 0.30 with dimensions 2 x 2 x 4mm.
Poussoir hydraulique plat.
Intake rocker arm rod for GM454 - 502 engine with roller tappets.
Length: 192 mm
Diameter: 7.93 mm - 5/16
Rocker arm kit for 4-cylinder and 6-cylinder in-line engines.
kit including:
- Rocker arms
- Nut
- Insert
Double valve spring with the following dimensions:
- External spring:
- External diameter: 36.4mm
- Inner diameter: 27mm
- Height: 51mm
- Inner spring:
- External diameter: 27mm
- Inner diameter: 20mm
- Height: 44.5mm
Rigid valve stem seal with the following dimensions:
Height: 12.5mm
Outer diameter: 17mm
Inner diameter: 14mm
Valve diameter: 7.8mm
Set of bearings for a standard size connecting rod with a diameter of 53.34mm and a width of 21.3mm.
Please note that for recent 4-cylinder 3-litre GM181 engines ONLY which have bearings with a width of 19mm, please refer to reference 23-804982.
Exhaust manifold gasket with small ports (32x39mm and 36x37mm) for 4-cylinder 3L GM181 engine.
Exhaust valve seat for GM BB engine with the following dimensions:
Exterior: 46mm
Interior: 39.45mm
Thickness: 5.85mm
Set of rings for a standard size piston with dimensions 2 x 2 x 4.76mm.
Set of rings for a piston in dimension 0.30 with dimensions 1.5 x 1.5 x 3mm.
Piston in standard size 101.60mm with thin rings of type 1.5x1.5x3mm.
Set of rings for a piston in dimension 0.20 with dimensions 5/64 x 5/64 x 3/16
Intake valve for GM454 -502 HO engines:
- Tail diameter: 9.45mm
- Head diameter: 55.62mm
Double valve spring with metal reinforcement with the following dimensions:
- External spring:
- External diameter: 39.5mm
- Inner diameter: 27mm
- Height: 59.2mm
- Inner spring:
- Outer diameter: 26.8mm
- Inner diameter: 19.4mm
- Height: 52.4mm
