Engine blocks

Quicksilver engine pack plus series 350 MPI Bravo 300CV

Compatible with the Bravo base, this engine is equipped with optimal durability thanks to Black-X valve technology.Leadless function 98, It is perfectly suited to replace 5.0L, 5.7L carburettor and single-point injection and compatible with SmartCraft digital gauges.

Main features:

- Fuel cooling Mercruiser GEN II,

- ECM 555,

- Protection Engine Guardian,

- Engine injection system Multipoint injection,

- Multipoint drain,

- Casting engine block,

- Exhaust collector in dry cast iron coated with electrodeposition paint,

- wet exhaust elbow,

- Raw water cooling,

- Integrated rinsing system,

- Training of accessories Snake belt,

- Lubrication High Flow oil pump 60 psi,

- Mechanical accelerator and reverser,

- Fake with 10 pin connector,

- SmartCraft connector,

- Maximum speed 4800 - 5200 RPM, kW with engine steering wheel 300 / 224

- Cylinder (CID/L) 350 / 5.7

- Gear and race 4,03 x 3,48" / 101.60 x 88 mm

- Compression rate 9.4:1

- Ethanol tolerance up to 10%.

- Alternator (amp/watt) 65 amp / 917 Watt

- Recommended oil Synthetic mix Mercury MerCruiser 25W-40, Synthetic mix FC-W certified NMMA

- Pistons Hypereutectic Alloy

- Cam shaft and roller pusher

- Culbuters 1.5:1 bottled

- Dimensions (L x l x h) 32 x 30 x 22" / 814 x 740 x 559 mm

- Weight (engine alone) 423 kg / 932 lbs

Mercury Marine and Quicksilver products have a one-year factory warranty against defects.Items such as engines, bass and platinums must be installed by a dealer for the warranty to be valid.

Quicksilver engine pack plus series 350 MPI Alpha 300CV

Compatible with the ALPHA One GEN1 and GEN2 base of ratio 1.47:1 and 1.81:1, this engine is equipped with optimal durability thanks to the technology of the Black-X valves.Leadless function 98, It is perfectly suited to replace 5.0L, 5.7L carburettor and single-point injection and compatible with SmartCraft digital gauges.

Main features:

- Fuel cooling Mercruiser GEN II,

- ECM 555,

- Guardian Engine Protection System,

- Engine injection system Multipoint injection,

- Multipoint drain,

- Casting engine block,

- Exhaust collector in dry cast iron coated with electrodeposition paint,

- wet exhaust elbow,

- Raw water cooling,

- Integrated rinsing system,

- Training of accessories Snake belt,

- Lubrication High Flow oil pump 60 psi,

- Mechanical accelerator and reverser,

- Fake with 10 pin connector,

- SmartCraft connector,

- Maximum speed 4800 - 5200 RPM, kW with engine steering wheel 300 / 224

- Cylinder (CID/L) 350 / 5.7

- Gear and race 4,03 x 3,48" / 101.60 x 88 mm

- Compression rate 9.4:1

- Ethanol tolerance up to 10%.

- Alternator (amp/watt) 65 amp / 917 Watt

- Recommended oil Synthetic mix Mercury MerCruiser 25W-40, Synthetic mix FC-W certified NMMA

- Pistons Hypereutectic Alloy

- Cam shaft and roller pusher

- Culbuters 1.5:1 bottled

- Dimensions (L x l x h) 32 x 30 x 22" / 814 x 740 x 559 mm

- Weight (engine alone) 423 kg / 932 lbs

NOTE:If used with an Alpha One (GEN1) engine, this engine requires the 46-8M0139983 sea water pump kit and the 57-865615Q03 wind belt (sold separately) for correct cooling.

Mercury Marine and Quicksilver products have a one-year factory warranty against defects.Items such as engines, bass and platinums must be installed by a dealer for the warranty to be valid.

Quicksilver Engine Pack More 3.0l TKS series

Compatible only with Alpha One base

Main features:

- TKS fuel pump with mechanical gasoline pump

- Multipoint drain

- Casting engine block,

- Exhaust collector in dry cast iron coated with electrodeposition paint,

- wet exhaust elbow,

- Raw water cooling

- Integrated rinsing system

- Training of accessories Trapezoidal Belt

- Lubrication High Flow oil pump 60 psi

- Mechanical accelerator and reverser

- Fake with 10 pin connector

- Maximum speed 4800 / 135cv

- Cylinder (CID/L) 181 / 3.0L

- Gear 101.60mm

- Compression rate 9.3:1

- Alternator (amp/watt) 65 amp / 917 Watt

- Recommended oil Synthetic mix Mercury MerCruiser 25W-40, Synthetic mix FC-W certified NMMA

- Pistons Hypereutectic Alloy

- Cam shaft and roller pusher

- Culbuters 1.5:1 bottled

- Dimensions (L x l x h) 730 x 565 x 526 mm

- Weight (engine alone) 257 kg

Mercury Marine and Quicksilver products have a one-year factory warranty against defects.Items such as engines, bass and platinums must be installed by a dealer for the warranty to be valid.

Engine block reconditioned in reverse rotation RH before 1990 for base GM V8 7.4 liters

Features :

- Rear crankshaft oil seal in 2 pieces

- GM454 generation IV engine base

- Oval intake passages

- Kit of 2 sprockets for distribution (without chain)

- Reverse rotation: ignition 1-2-7-5-6-3-4-8

- Drilling for the fuel pump shaft

Engine including:

- Rocker cover (G6 type aluminum)

- Sheet metal oil pan

- Timing cover

- Damper before

- Intake and exhaust gaskets

Perfect product for replacing your Crusader, Chriscraft, RIVA engine...

Engine reconditioning integrates the rectification, machining, replacement and control of all the key elements in order to provide you with a marine engine block capable of replacing your old engine.

Engine including superior quality internal parts to meet marine requirements.

Repacked engine block in reverse HR before 1990 for GM V8 5.7 litres base with 12 attachment screws for intake pipe.

Characteristics :

- Rear spi of vilebrequin in 2 pieces

- 12 attachment screws for intake pipe

- Cache asbuteurs fixation extérieur

- 2 pinion kit for distribution (without chain)

Reverse rotation: ignition 1-2-7-5-6-3-4-8

- drilling for the gas pump axis

Perfect product for the replacement of your Crusader 350 - 327, Chriscraft ,RIVA...

The engine reconditioning incorporates the rectification, machining, replacement and control of all key elements to provide you with a marine engine block that can replace your old mechanics.

Reconditioned motor block in standard LH rotation before 1990 for base GM V8 5 litres with 12 attachment screws for intake pipe.

Characteristics :

- Rear spi of vilebrequin in 2 pieces

- 12 attachment screws for intake pipe

- Cache asbuteurs fixation extérieur

- Standard rotation: ignition 1-8-4-3-6-5-7-2

- drilling for the gas pump axis

Perfect product for replacing your Crusader, Mercruiser, Volvo, WTO ...

The engine reconditioning incorporates the rectification, machining, replacement and control of all key elements to provide you with a marine engine block that can replace your old mechanics.

Reconditioned engine block for GM V6 4.3 liter base after 1990 Vortec type with 8 fixing screws for the intake pipe.

Features :

- One-piece rear crankshaft oil seal

- PLASTIC timing cover

- Roller camshaft

- Balancing shaft

- 8 fixing screws for the intake pipe

- Central fixing rocker cover

- Rocker arm with a bearing

- Cylinder head carrying casting #113

- Aluminum oil pan

Engine including:

- Plastic rocker covers

- Timing cover with probe hole

- Aluminum oil pan

- Damper before

- Exhaust and intake gaskets

Perfect product for replacing your 4.3GXI, 4.3MPI engine...

Engine reconditioning integrates the rectification, machining, replacement and control of all the key elements in order to provide you with a marine engine block capable of replacing your old engine.

Engine including superior quality internal parts to meet marine requirements.
